Selecting your paper path (bin 1 or bin 2)
When the double-bin cut-sheet feeder is installed, the
high-capacity cut-sheet feeder becomes bin 1 and the single-bin
cut-sheet feeder becomes bin 2 for paper path selection
purposes.
It is best to select the paper path in your application program
because software settings usually override the printer’s control
panel settings. However, if you cannot select the paper path in
your application, select a path by pressing the
Tear off/Bin
button until the light indicates the bin you want as shown
below.
The cut-sheet feeder you selected automatically loads paper
when the printer receives data.
bin 2: single-bin cut-sheet feeder
bin 1: high-capacity cut-sheet feeder
g4-17
n
On: bin 1 (high-capacity cut-sheet feeder) is selected.
o
Off: bin 2 (single-bin cut-sheet feeder) is selected.
g-panel1
L
Gentian Rev.c
A5 size Chapter 4
97/06/20 pass 0
4-16
Printing on Single Sheets
