3. Insert the tractor into the printer’s mounting slots and press
down both ends of the tractor to make sure that it is firmly
seated.
See the next section for instructions on loading continuous
paper with the front push tractor.
To remove the tractor, first remove any paper from it as
described on page 3-11. Then press the tractor’s lock tabs and
tilt the tractor up and out of the printer.
Loading paper with the front push tractor
1. Make sure the printer is turned off, and open the front cover.
Also make sure the tractor is installed in the front push
position.
2
1
G3-8a
G3-9
3
R
Gentian Rev.c
A5 size Chapter 3
97/07/04 pass 2
Printing on Continuous Paper
3-7
