Epson LX-300+ Service Manual

LX-300+/1170 Revision C
PRODUCT DESCRIPTION
S
PECIFICATIONS 10
1.2 SPECIFICATIONS
1.2.1 Printing Specification
o Print method: Impact dot matrix
o Number of pins: 9 pins
o Print pin arrangement: 9 x 1
o Print pin diameter: 0.29 mm (0.0114 inch)
o Color (Option): Black, Magenta, Cyan, Yellow
o Print direction: Bi-direction with logic seeking
o Print speed and printable columns:
o Resolution:
Table 1-1. Print Speed and Printable Columns
Printing mode Character pitch (cpi) Printable columns Printing speed (cps)
High speed draft
10
80(LX-300+)
136(LX-1170)
300
12
96(LX-300+)
163(LX-1170)
337
15
120(LX-300+)
204(LX-1170)
337
High speed draft
condensed
17
137(LX-300+)
233(LX-1170)
321
20
160(LX-300+)
272(LX-1170)
300
Draft
10
80(LX-300+)
136(LX-1170)
225
12
96(LX-300+)
163(LX-1170)
270
15
120(LX-300+)
204(LX-1170)
225
Draft condensed
17
137(LX-300+)
233(LX-1170)
191
20
160(LX-300+)
273(LX-1170)
225
Draft emphasized
10
80(LX-300+)
136(LX-300+)
112
NLQ
10
80(LX-300+)
136(LX-1170)
56
12
96(LX-300+)
163(LX-1170)
67
15
120(LX-300+)
204(LX-1170)
56
17
137(LX-300+)
233(LX-1170)
47
20
160(LX-300+)
272(LX-1170)
56
NOTE: When the power supply voltage drops to the lower limit, the printer
stops printing and then starts printing the rest on the line more slowly
than before.
Table 1-2. Resolution
Printing mode
Horizontal density
(dpi)
Vertical density
(dpi)
Adjacent dot print
High speed draft 90 72 No
Draft 120 72 No
Draft condensed 240 72 No
Draft emphasized 120 72 Yes
Table 1-1. Print Speed and Printable Columns
Printing mode Character pitch (cpi) Printable columns Printing speed (cps)

Epson LX-300+ Specifications

General

Emulation	Epson ESC/P, IBM PPDS
Print Method	9-pin, impact dot matrix
Interface	Parallel
Paper Handling	Friction feed
Dimensions	366 x 275 x 159 mm
Paper Width	4 - 10 inches
