Epson LX-300+ Service Manual

LX-300+/1170 Revision C
PRODUCT DESCRIPTION Physical Specifications 42
1.8.2 Physical Specifications for LX-1170
o Physical Specifications for World Wide (Without pull tractor)
n Dimensions: 366 x 275 x 159 mm (WxDxH)
n Mass: Approx. 4.4 kg
n Appearance: See the figure below.
Figure 1-11. Appearance Without Pull Tractor (LX-1170)
o
Physical Specifications (CSF)
n Dimensions: 366 x 441 x 370 mm (WxDxH)
n Mass: Approx. 4.6 kg
n Appearance: See the figure below.
n

Epson LX-300+ Specifications

General

Emulation	Epson ESC/P, IBM PPDS
Print Method	9-pin, impact dot matrix
Interface	Parallel
Paper Handling	Friction feed
Dimensions	366 x 275 x 159 mm
Paper Width	4 - 10 inches
