Epson LX-300+ Service Manual

LX-300+/1170 Revision C
PRODUCT DESCRIPTION
S
PECIFICATIONS 16
1.2.3 Electrical Specification
o 120 V version
n Rated voltage: AC 120V
n Input voltage range: AC 99 to 132 V
n Rated frequency range: 50 to 60 Hz
n Inputfrequencyrange: 49.5to60.5Hz
n Rated current: 0.6A (max. 1.4A)
n Power consumption: Approx. 23W (ISO/IEC 10561 Letter pattern)
n Insulation resistance:10M Ω min.
(between AC line and chassis, DC 500V)
n Dielectric strength: AC 1000 Vrms. 1 min. or
AC 1200 Vrms. 1 sec.
(between AC line and chassis)
o 230 V version
n Rated voltage range: AC 220 to 240 V
n Input voltage range: AC 198 to 264 V
n Rated frequency range: 50 to 60 Hz
n Inputfrequencyrange: 49.5to60.5Hz
n Rated current: 0.3 A (max. 0.7A)
n Power consumption: Approx. 23W (ISO/IEC10561 Letter pattern)
Energy Star Complaint
n Insulation resistance: 10M Ω min.
(between AC line and chassis, DC 500V)
n Dielectric strength: AC 1500 Vrms. 1 min.
(between AC line and chassis)
1.2.4 Environmental Condition
o Temperature: 5 to 35 °C (operating*
1
)
15 to 25
°C (operating*
1,
*
2
)
-30to60
°C (non-operating)
o Humidity: 10 to 80% RH (operating*
1
)
30 to 60% RH (operating
*
1,
*
2
)
0 to 85% RH (non-operating
*
1
)
o Resistance to shock: 1 G, within 1ms (operating)
2 G, within 2ms (non-operating
*
3
)
o Resistance to vibration: 0.25 G, 10 to 55 Hz (operating)
0.50 G, 10 to 55 Hz (non-operating
*
3
)
*1: without condensation
*2: during printing on reclaimed paper, multi part paper, envelop, label or
roll paper.
*3: without shipment container
1.2.5 Reliability
o Total print volume: 12 million lines (except printhead)
o MTBF: 6000 POH(25% Duty)
o Printhead life: 400 million strokes / wire (Black)
LX-300+ 100 million strokes / wire (Color)
1.2.6 Ribbon Cartridge
o Type: Fabric
Color: Black
Ribbon life: 3 million characters
(Draft 10 cpi, 14 dots/character)
o Type: Fabric
Color: Black, Magenta, Cyan and Yellow
Ribbon life:
n Black 1 million characters (Draft 10 cpi, 14 dots/character)
n Magenta 0.7 million characters (Draft 10 cpi, 14 dots/character)

Epson LX-300+ Specifications

General

Emulation	Epson ESC/P, IBM PPDS
Print Method	9-pin, impact dot matrix
Interface	Parallel
Paper Handling	Friction feed
Dimensions	366 x 275 x 159 mm
Paper Width	4 - 10 inches
