LX-300+/1170 Revision C
Appendix EEPROM Address Map
07
7.2 EEPROM Address Map
This section provides the EEPROM address map.
NOTE: The data of two or more byte are assigned as lower byte to lower address
and higher byte to higher address.
*1: The data are fixed by each printer hardware in the factory. The data
should not be changed afterwards.
Table 7-13. EEPROM Address Map
Address
Explanation Setting
QPIT
Settings
Factory
Settings
Area 0
00H-
03H
Reserved 00H 00H
04H-
07H
Driving Line count
for ribbon change
timing
0-0FFFFFFFFH(count)
SeeRemotespecTLcmd
00000000
H
00000000
H
08H-
0BH
Driving Hour
0-0FFFFFFFFH(minute)
SeeRemotespecTLcmd
00000000
H
00000000
H
0CH-
0FH
Driving Line count
0-0FFFFFFFFH(count)
SeeRemotespecTLcmd
00000000
H
00000000
H
10H Starting Year
0-99(the last two figures of Anno
Domini)
SeeRemotespecSDcmd
00H 00H
11H Starting Month
0-12
SeeRemotespecSDcmd
00H 00H
12H Starting Data
0-31
SeeRemotespecSDcmd
00H 00H
13H Backup Flag1
b0: In Tear Off state (0=No,
1=Yes)
b1 to b7: Reserved
00H 00H
14H,15
H
Paper edge length
0 to 22x432 by 0.0588mm
(1/432inch)
00H 00H
Area1
22H,23
H
Character table
selection
0: PC437 21: Code MJK
1: PC850 22: Bulgaria
2: PC860 23: Estonia
3: PC863 24: PC774
4: PC865 25: IC8859-2
5: PC861 26: PC866LAT
6: BRASCII 27: PC866UKR
7: Abicomp 28: Hebrew 7
8: ISO Latin 1 29: Hebrew 8
9: Roman 8 30: PC862
10: PC437Greek 31: PCAPTEC
11: PC852 32: PC708
12: PC853 33: PC720
13: PC855 34: PCAR864
14: PC857 35: PC858
15: Reserved 36: ISO 8859-15
16: PC866 37: PC771
17: PC869
18: ISO Latin 1T
19: ISO 8859-7
20: MAZOWIA
0000H
(PC437)
0000H
(PC437)
40: Italic U.S.A
41: Italic France
42: Italic Germany
43: Italic U.K.
44: Italic Denmark
45: Italic Sweden
46: Italic Italy
24H,25
H
Page langth for
tractor
1 to 22x432 by 0.0588mm (1/432
inch)
0000H: 279.4mm (11 inches:
same as default
0000H 0000H
Table 7-13. EEPROM Address Map (continued)
Address
Explanation Setting
QPIT
Settings
Factory
Settings
To Next Page
