Epson LX-300+ Service Manual

LX-300+/1170 Revision C
PRODUCT DESCRIPTION
O
peration 27
o
Operation in default setting mode
The following switches are used in default setting mode;
1.4.1.2 LED
o Indication in normal mode
*1 Pause (Orange)
-It is on when the printer is paused, and it is off when the printer is not paused.
-It blinks when Micro Adjust is enabled.
*2 Paper Out (Red)
-It is on when the printer is in the Paper out status, and it is off when the printer is out
of this status.
*3 Font (Green)
-The status of Font selection is displayed by 2 Font LEDs when continuous paper is out
of the Tear-off position.
-Both LEDs blink when continuous paper is in the Tear-off position.
n ¨ :Draft
n « :DraftCondensed
¨ n :Roman
¨¨ : Roman Condensed
¨« : Sans serif
« n : Sans serif Condensed
«« :TearOff
(
¨ :LEDOn, n :LEDOff, « : LED Blinks)
1.4.1.3 Buzzer
o Paper out error: Beeper sounds (...)*
o Release lever operation: Beeper sounds(-----)*
o Illegal panel operation: Beeper sounds (.)*
*The description (.) and (-) in the above shows how the beeper sounds.
(.): Beeper sounds approx. 100ms and interval is approx. 100ms.
(-): Beeper sounds approx. 500ms and interval is approx. 100ms.
Table 1-17. Operation at Power On
Switch Function
Tear Off Changes the setting.
LF/FF Selects the Menu.
The others Not available.
Table 1-18. Indication in normal mode
LED
Pause
*1
Paper
Out
*2
Font
Printer Status
Pause On --- ---
Paper out error On On ---
Release lever error On --- ---
Paper eject warning On Blink ---
Micro Adjust Blink --- ---
Tear off --- --- *3
Font selection --- --- *3
Fatal error Blink Blink Blink

Epson LX-300+ Specifications

General

Emulation	Epson ESC/P, IBM PPDS
Print Method	9-pin, impact dot matrix
Interface	Parallel
Paper Handling	Friction feed
Dimensions	366 x 275 x 159 mm
Paper Width	4 - 10 inches
