peration 29
5. Select setting value by LF/FF button.
Tear Off/ Bin LEDs and Paper Out LED show that menu’s value by status of On/Off/
Blink/2-Blinks. That value can be changed by pressing Tear Off/ Bin button and the
LEDs status of On/Off/Blink/2-Blinks will be changed as the button is pressed.
6. When LF/FF button is pressed, the printer memorize the last setting value.
7. Repeat (4) to (6).
The other items can be changed in the same manner.
The menu selection will return to the first menu after the last menu selection is over.
8. Turn the printer off.
The setting is stored into non-volatile memory.
1.4.2.4 Bi-d. Adjustment
Bi-d. adjustment can be adjusted by users. Bi-d. adjustment method is as follows.
1. Turning the printer on while pressing Pause switch. The guide to adjust Bi-d alignment
in this mode and the first alignment pattern will be printed.
2. Select the most closely aligned number by pressing LF/FF (
↓
) and Load/Eject (
↑
)
switches.
Font LEDs and Pause LED show the pattern number which is selected at that time. The
selection is advanced one by one as the switch is pressed, and the combination of On/
Off/Blink of those three LEDs is also changed according to the selection.
Table 1-19. Setting Menu
Item Setting / Value *2
Page length for tractor
3 inch, 3.5 inch, 4 inch, 5.5 inch, 6 inch, 7 inch, 8 inch, 8.5
inch, 11 inch, 70/6 inch, 12 inch, 14 inch, 17 inch
Skip over perforation OFF,ON
Auto tear off OFF,ON
Auto line feed OFF,ON
Print direction Bi-d.,Uni-d.,Auto
Software ESC/P2, IBM 2390 Plus
0slash OFF, ON
High speed draft OFF, ON
I/F mode Auto, Parallel, Option
Auto I/F wait time 10 seconds, 30 seconds
Baud rate
19200BPS, 9600BPS, 4800BPS, 2400BPS, 1200BPS,
600BPS, 300BPS
Parity None, Odd, Even, Ignore
Data length 8bit,7bit
Parallel I/F bidirectional mode OFF, ON
Packet mode Auto,OFF
Character table Software version
Italic, PC437, PC850, PC860, PC863, PC865, PC861,
BARASCII, Abicomp, Roman8, ISO Latin 1, PC858, ISO
8859-15
NLSP version
Italic, PC437, PC850, PC437, Greek, PC853, PC855,
PC852, PC857, PC864, PC866, PC869, MAZOWIA, Code
MJK, ISO 8859-7, ISO Latin 1T, Bulgaria, PC774, Estonia,
ISO 8859-2, PC 866 LAT., PC 866UKR, PC APTEC,
PC708, PC720, PCAR 864, PC860, PC865, PC861, PC863,
BRASCII, Abicomp, Roman8, ISO Latin 1, PC858, ISO
8859-15, PC771
International character set
for Italic table
Italic U.S.A., Italic France, Italic Germany, Italic, U.K.,
Italic Denmark 1, Italic Sweden, Italic Italy, Italic Spain 1
Manual feed wait time 1 second, 1.5 seconds, 2 seconds, 3 seconds
Buzzer OFF, ON
Auto CR (IBM 2380 Plus)
*1
OFF,ON
IBM character table
*1
Table2,Table1
NOTE: *1: This setting is effective when IBM 2380 Plus emulation is selected.
NOTE: Setting with underline mean the standard factory settings.
NOTE: After W1xxxx Version.
Table 1-19. Setting Menu
