LX-300+/1170 Revision C
PRODUCT DESCRIPTION
ontrol codes 36
o
Paper_path
o characteristic status code
o MIB proxy information
“1G:”
“0305NA,” Sheet feeder bin 1 (removable), capacity 5mm,
quantity of paper N.A.
“09NANA,” Manual feed rear, capacity N.A., quantity of paper N.A.
“0CNANA;” Tractor rear, capacity N.A., quantity of paper N.A.
“TEC:06;” 9pin SIDM
1.5.3.2 Packet commands
Table 1-29. Paper_Path
paper_path “<paper_path code>”
Continuous paper (rear) “0000”
Continuous paper (bottom) “0001”
Cut sheet (rear) “0200”
CSF Single bin “0100”
Table 1-30. Characteristic Status Code
location size type Refer to
Structure version +0 2bytes “02” fixed -
Starting date +2 6bytes “yy”, “mm, “dd” “SD” command
Total printing line number +8 8bytes “nnnnnnnn” “TL” command
Total power on hour +16 4bytes “nnnn” “TL” command
Total printing number for
ribbon charge timing
+20 8bytes “nnnnnnnn” “TL” command
Table 1-31. Packet Commands
Function Code
Device ID request “di” 01H 00H 01H
Device ID reply (*1) “@EJL” SP “ID” CR LF <Device ID string> FF
State-Reply request “st” 01H 00H 01H
State-Reply (*2) “@BDC” SP “ST” CR LF <printer status string> FF
No support command
“XX
:;” FF
(XX is the command string being invalid.)
NOTE: (*1) The reply string is as same as BDC-ID Reply.
NOTE: (*2) The reply string is as same as BDC-ST Reply.
