LX-300+/1170 Revision C
Appendix Parts List
19
7.5 Parts List
The following table shows parts name of this product. Refer to the exploded diagrams for
parts’ number.
o Parts List for LX-300+
Table 7-14. LX-300+ Parts List
Number Parts Name
100 “HOUSING ASSY.,LOWER”
101 INSULATOR;A
102 INSULATOR;B
103 “HOUSING,UPPER”
104 “SHIELDPLATE,LOWER”
105 “COVER ASSY.,PRINTER”
106 KNOB;W
109 SHEET GUIDE ASSY.
111 “SHIELDPLATE,UPPER”
115 “COVER CONNECTOR,CS;W”
116 HEXAGON NUT
117 GROUNDINGPLATE
118 “GROUNDING PLATE,PANEL”
119 EDGING;A
120 LOGO PLATE
123 “FERRITE CORE,FPC-25-20”
124 “SHEET,PROTECT”
125 CONNECTOR LOCK NUT
126 RIVET B-TITE(SCREW TYPE)
127 “C.B.P-TITE,3X10,F/ZN”
128 C.B.S. SCREW
129 “C.B.B-TITE(P(13)),3X14,F/ZN”
130 C.B.(O) SCREW 4X8 F/ZG
131 C.P.SCREW
132 C.B.S. SCREW
180 “GUIDE,STACKER”
200 “BOARD ASSY.,MAIN”
320 HARNESS
300 “BOARD ASSY.,POWER SUPPLY”
400 POWER CABLE ASSY.
450 “BOARD ASSY.,PANEL”
451 “SHEET,PANEL”
500 “PRINTER MECHANISM,M-3M10-100”
501 “FRAME,LEFT” (This name is not fixed.)
502 “FRAME,RIGHT”
503 “MOTOR ASSY.,CR”
504 “EXTENSION SPRING,8.10”
505 “LEVER ASSY.,PLANET”
506 “SHAFT,CR,GUIDE”
509 “SPURGEAR,13.2”
510 “COMBINATIONGEAR,5.1,16.2”
511 “MOTOR ASSY.,PF”
512 “COVER,RD”
513 “RATCHET,RD”
514 “DETECTOR,LEAF,B1”
Table 7-14. LX-300+ Parts List
Number Parts Name
