Epson LX-300+ Service Manual

LX-300+/1170 Revision C
PRODUCT DESCRIPTION Physical Specifications 41
1.8 Physical Specifications
1.8.1 Physical Specifications for LX-300+
o Physical Specifications (Without pull tractor)
n Dimensions: 366 x 275 x 159 mm (WxDxH)
n Mass: Approx. 4.4 kg
n Appearance: See the figure below.
Figure 1-9. Appearance Without Pull Tractor (LX-300+)
o
Physical Specifications (CSF)
n Dimensions: 366 x 441 x 370 mm (WxDxH)
n Mass: Approx. 4.6 kg
n Appearance: See the figure below.
Figure 1-10. Appearance With CSF (LX-300+)

Epson LX-300+ Specifications

General

Emulation	Epson ESC/P, IBM PPDS
Print Method	9-pin, impact dot matrix
Interface	Parallel
Paper Handling	Friction feed
Dimensions	366 x 275 x 159 mm
Paper Width	4 - 10 inches
