Epson LX-300+ Service Manual

LX-300+/1170 Revision C
PRODUCT DESCRIPTION Paper Specifications 40
o
Labels
Table 1-36. Continuous Paper with Labels
Figure 1-8. Printable Area - Label
o
Roll paper
Table 1-37. Roll Paper
Rear Entry Bottom Entry
Min. Max. Min. Max.
Label size
--- See the figure below.
Base sheet width
(inch)
(mm)
--- ---
(4)
101.6
(10)
254
Base sheet length
(one page)
(inch)
(mm)
--- ---
(4)
101.6
(22)
558.8
Base sheet thickness
(inch)
(mm)
--- ---
(0.0028)
0.07
(0.0035)
0.09
Total thickness
(inch)
(mm)
--- ---
(0.0063)
0.16
(0.0075)
0.19
Label weight
(g/m
2
)
(lb.)
---
64
(17)
Quality
---
AVERY CONTINUOUS
FORM LABELS, AVERY
MINI-LINE LABELS or the
same quality labels
NOTE: Printing on labels is available only under normal temperature and
humidity conditions.
NOTE: The base sheet of labels must be continuous paper.
NOTE: Continuous paper with labels should be inserted from the bottom
entrance.
Minimum Maximum
Width
(inch)
(mm)
(8.5)
216
Length
(inch)
(mm)
---
Thickness
(inch)
(mm)
(0.0028)
0.07
(0.0035)
0.09
Weight
(g/m
2
)
(lb.)
52
(14)
82
(22)
Quality Plain paper, Not curled, not folded, not crumpled
63.5 mm (2.5 inch) min.
23.8 mm
(15/16inch)
min.
R_2.5 mm (0.1 inch) min.
Label

Epson LX-300+ Specifications

General

Emulation	Epson ESC/P, IBM PPDS
Print Method	9-pin, impact dot matrix
Interface	Parallel
Paper Handling	Friction feed
Dimensions	366 x 275 x 159 mm
Paper Width	4 - 10 inches
