LX-300+/1170 Revision C
Appendix EEPROM Address Map
08
26H,27
H
0000H 0000H
28H,29
H
Page langth for CSF
1 to 22x432 by 0.0588mm (1/432
inch)
0000H: 558.8mm (22 inches:
same as default
0000H 0000H
2AH,
2BH
Reserved 0000H 0000H
2CH,
2DH
TOP adjustment
value for tractor
-144 to 432 (0.0mm to 8.5mm
+25.4mm (inch), by 0.0588mm
(1/432 inch))
*Minimum value depends on the
value of 5CH-5DH
0000H
(8.5mm)
0000H
(8.5mm)
2EH,
2BH
Reserved 0000H 0000H
30H -
31H
TOP adjustment
value for CSF
-144 to 432 (0.0mm to 8.5mm
+25.4mm (inch), by 0.0588mm
(1/432 inch))
*Minimum value depends on the
value of 5CH-5DH
0000H
(8.5mm)
0000H
(8.5mm)
32H,
33H
Reserved 0000H 0000H
34H -
35H
TOP adjustment
value for rear
manual insertion
-144 to 432 (0.0mm to 8.5mm
+25.4mm (inch), by 0.0588mm
(1/432 inch))
*Minimum value depends on the
value of 5CH-5DH
0000H
(8.5mm)
0000H
(8.5mm)
36H,
37H
Reserved 0000H 0000H
38H,
39H
Bottom margin for
tractor
1 to 22x432 by 0.0588mm (1/432
inch)
0000H: 279.4mm (11 inches:
same as default
0000H 0000H
Table 7-13. EEPROM Address Map (continued)
Address
Explanation Setting
QPIT
Settings
Factory
Settings
3AH,
3BH
Reserved 0000H 0000H
3CH Font selection
0: Draft
1: Roman
2: Sans serif
00H
(Draft)
00H
(Draft)
3DH Pitch selection
0: 10 cpi 3: 17 cpi
1: 12 cpi 4: 20 cpi
2: 15 cpi 5: Proportional
00H
(10cpi)
00H
(10cpi)
3EH,
3FH
Reserved 0000H 0000H
40H
Print direction
setting
0: Bi-d.
1: Uni-d
00H
(Bi-d)
00H
(Bi-d)
41H-
43H
Reserved 0000H 0000H
44H
Auto line feed
Auto tear off
Skip over
perforation
High speed draft
----
----
----
----
b0: Auto line feed (0: off 1: on)
b1: Auto tear off (0: off 1: on)
b2: Skip over perforation
(0: off 1:on)
b3: High speed draft
(0: on 1: off)
b4: Reserved
b5: Reserved
b6: Reserved
b7: Reserved
00H 00H
Table 7-13. EEPROM Address Map (continued)
Address
Explanation Setting
QPIT
Settings
Factory
Settings
Reserved
To Next Page
