Epson LX-300+ Service Manual

LX-300+/1170 Revision C
Appendix Parts List
1
22
450 "BOARD ASSY.,PANEL"
451 "SHEET,PANEL"
300 "BOARD ASSY.,POWER SUPPLY"
320 HARNESS
400 "POWER CABLE,BS31303SA-SR-10A"
401 HARNESS
500 "PRINTER MECHANISM(ASP),M-3N60-100"
501 "FRAME ASSY.,LEFT"
502 "FRAME,RIGHT"
503 "MOTOR ASSY.,CR"
504 "EXTENSION SPRING,8.10"
505 "LEVER ASSY.,PLANET"
506 "SHAFT,CR,GUIDE"
507 RETAINING RING
508 "GROUNDING PLATE,PAPER GUIDE,UPPER"
509 "SPURGEAR,13.2"
510 "COMBINATIONGEAR,5.1,16.2"
511 "MOTOR ASSY.,PF"
512 "COVER,RD"
513 "RATCHET,RD"
514 "DETECTOR,LEAF,B1"
515 "GROUNDING WIRE,PLATEN"
516 "PULLEY ASSY.,DRIVEN"
517 "HARNESS,HP"
518 C.P.B SCREW
Table 7-15. LX-1170 Parts List
Number Parts Name
519 "ROLLER,PAPER EJECT"
520 PAPER GUIDE
521 "DETECTOR,PE,REAR"
522 "HARNESS,PE,REAR"
523 "DETECTOR,PE,BOTTOM"
524 "HARNESS,PE,BOTTOM"
525 "HOLDER,ROLLER,PF"
526 "ROLLER,PF,DRIVEN"
527 "ROLLER,PF,DRIVE,REAR;B"
528 "COMPRESSION SPRING,13.72"
529 "SHAFT,RELEASE"
531 RETAINING RING
532 "BUSHING,11"
533 "U-TYPE,11.2X0.13X16S/NA"
534 PLAIN WASHER
535 PLATEN
536 CARRIAGE SUB ASSY.
537 "GROUNDING PLATE,HEAD"
538 OIL PAD
539 "LEVER,G,ADJUST"
540 RIBBON MASK
541 TIMMING BELT
542 "BUSHING,PARALEL,ADJUST"
543 "CABLE,HEAD"
544 "HARNESS,PG"
Table 7-15. LX-1170 Parts List
Number Parts Name

Epson LX-300+ Specifications

General

Emulation	Epson ESC/P, IBM PPDS
Print Method	9-pin, impact dot matrix
Interface	Parallel
Paper Handling	Friction feed
Dimensions	366 x 275 x 159 mm
Paper Width	4 - 10 inches
