LX-300+/1170 Revision C
Disassembly and Assembly
O
verview 71
Table 4-3. List of Screws
Screw Name Screw Name
C.B.P., Tite, 3x10 F/ZN C.P., Screw, 3x4 F/ZN
C.P.B., Screw, 3x14 F/ZN C.B(O), Screw, 4x8 F/ZN
C.B.S., Screw, 3x4 F/Zn Jack Socket
C.B.B., (W(13), 3x14 F/ZN
