LX-300+/1170 Revision C
Disassembly and Assembly Disassembly and Assembly 77
5. Lift the printer mechanism a little bit and remove harnesses from the main board
assembly.
Figure4-5. Harness Removal
6. Remove the printer mechanism.
A D J U S T M E N T
R E Q U I R E D
Perform Bi-D adjustment after removing the printer mechanism.
Printer Mechanism
Main Board Assembly
