5-8 Disassembly, Assembly, and Adjustment Rev. A
Confidential
④ Once the board is released from the plate (marked with ④), the main circuit board can be
removed from the printer.
Refer to the corresponding assembly sections in this chapter for assembly procedures.
connectors
connector
connectors
screws
screws
