8 • Actuation Configurations for ICC 300
14
1. Position the neutral electrode on the patient. Connect neutral electrode
to the ICC 300.
2. Plug HF plug of the electrode handle
into the CUT / COAG socket
for finger switches.
3. Connect bipolar instrument
to BIPOLAR socket.
of the equipment trolley.
ICC 300 and APC 300.
1. Open the cylinder valves on the argon gas cylinders in a clockwise
direction until they stop.
2. Check fill level of the argon cylinders (fill level of the argon cylinders
is in the information line of the standard display). Always
keep a full replacement cylinder at the ready.
1. Set AUTO COAG field to SPRAY. Displayed: 60 (power limit 60 W)
2. Select the desired power limit.
Select effect and power limit in the AUTO CUT field.
Position P
EDAL key to AUTO COAG field. Imperative!
Select a power limit in the AUTO BIPOLAR field. Select an AUTO START
mode, or actuate via the white single-pedal foot switch.
7. Set ICC for APC
3. Connect instruments,
neutral electrode to ICC
4. Plug in mains plug
5. Switch on
6. Open cylinder valves
8. Set ICC for ARGON CUT
10. Set ICC for bipolar
coagulation
9. P
EDAL
key
WARNING!
