19
Actuation Configurations for ICC 350 • 8
APC probe for flexible endoscopes, consisting of: cable and probe
1. Screw the bacteriological filter
to the argon socket.
2. Screw the cable's argon connection
to the filter.
3. Plug the cable's multiple plug
into the multiple socket.
4. Connect the cable to the APC probe.
Is the automatic setting of the COAG flow suitable for the application?
Press P
UR key and rinse the probe with argon.
Carry out functional test as described in CHAPTER 3 à.
Press the blue pedal.
Introduce the sterile APC probe into the work channel of the endoscope.
9. Connect APC probe
10. Check flow
11. Rinse probe
12. Functional test
13. Actuate APC
14. Introduce probe into the
endoscope
