8 • Actuation Configurations for ICC 350
26
3. Connect instruments,
neutral electrode to ICC 350
1. Position the neutral electrode on the patient. Connect neutral electrode
to the ICC 350.
2. Plug HF plug of the electrode handle
into the CUT / COAG 2 socket.
3. Connect bipolar instrument
to BIPOLAR socket of the ICC 350.
of the equipment trolley.
ICC 350 and APC 300.
1. Open the cylinder valves on the argon gas cylinders in a clockwise
direction until they stop.
2. Check fill level of the argon cylinders (fill level of the argon cylinders
is in the information line of the standard display). Always keep a full
replacement cylinder at the ready.
1. Set AUTO COAG 1 to SPRAY. Displayed: 60 (power limit 60 W)
2. Select the desired power limit.
Select effect and power limit in the AUTO CUT field.
The P
EDAL key associates the blue foot switch with the coagulation mode
of the electrode handle or with the bipolar instrument.
Select a power limit in the AUTO BIPOLAR field. Select an AUTO START
mode, or actuate via the blue foot switch if the PEDAL key is positioned to
the AUTO BIPOLAR field.
4. Plug in mains plug
5. Switch on
6. Open cylinder valves
7. Set ICC 350 for APC
8. Set ICC 350 for ARGON CUT
9. P
EDAL
key
10. Set ICC 350 for bipolar
coagulation
WARNING!
