4 • Technical Data
16 / 84
80116-938_V24392
2023-03
Ethernet
Ethernet optional (deactivated as standard)
Dimensions and weight
Width x height x depth 415 x 215 x 375 mm
Weight 12 kg
Display size 10.4 inch
Ambient conditions for transport and storage of unit
Temperat u re -30°C to +70°C
Relative humidity 10% – 90%
Ambient conditions for operation of unit
Temperat u re +10 °C to +40 °C
Relative humidity 15% – 80%, non-condensing
Air pressure 54 kPa – 106 kPa
Maximum operating altitude 5000 m above sea level
Acclimatizing
If the unit has been stored or transported at temperatures below +10 °C or above +40 °C, the unit will
require approx. 3
hours to acclimatize at room temperature.
Standards
Classification according to EC Directive 93/42/EEC II b
Classification according to Regulation (EU) 2017/
745
II b
Protection class as per EN 60 601-1 I
Type as per EN 60 601-1 Defibrillation-proof type CF applied part
