7 • Maintenance and servicing
80116-938_V24392
2023-03
autoCUT, effect 1 1. Set the test specimen to:
Electrode handle, monopolar – autoCUT – Effect 1
2. Set HF power meter to:
RL = 5200 Ohm
3. Activate test specimen via CUT button on the electrode handle.
4. Set the zero line on the oscilloscope. To do so:
– Set the picture so that the positive half wave is clearly displayed.
– Terminate activation of the test specimen and determine the zero
line with a cursor line (the probe has an offset value, which can
also be negative).
5. Use the CUT button of the electrode handle to activate the test speci-
men again.
6. On the oscilloscope, put the second cusor line in the peak of the posi-
tive half wave and determine the measure value for the peak voltage
from the delta.
7. Determine and document the measured value. The tolerance range is
219 to 267 V
p
.
HF peak voltage for modulated modes
Testing and measuring equipment
Erbe Art. No. Description
20192-127 Patient cable AE
or
20192-110 Patient cable AE, international
20190-045 Electrode handle ICC/ACC
– Laboratory measuring cable
20194-070 Patient cable NE
or
20194-075 Patient cable NE, international
20100-033 Adapter cable NE
– HF power meter
– High Voltage Differential Probe
– Oscilloscope
