Erbe VIO 3 - Monopolar and Bipolar Power Output Tests

7 • Maintenance and servicing
78 / 84
80116-938_V24392  2023-03
swiftCOAG, effect 4 1. Set the test specimen to:
Electrode handle, monopolar – swiftCOAG – Effect 4
2. Set HF power meter to:
RL = 5200 Ohm
3. Use the COAG button of the electrode handle to activate the test
specimen.
4. Set the zero line on the oscilloscope. To do so:
– Set the picture so that the positive half wave is clearly displayed.
– Terminate activation of the test specimen and determine the zero
line with a cursor line (the probe has an offset value, which can
also be negative).
5. Use the COAG button of the electrode handle to activate the test
specimen again.
6. On the oscilloscope, put the second cusor line in the peak of the posi-
tive half wave and determine the measure value for the peak voltage
from the delta.
7. Determine and document the measured value. The tolerance range is
901 to 1101 V
p
.
HF output power, CUT, monopolar
Testing and measuring equipment
Erbe Art. No. Description
20192-127 Patient cable AE
or
20192-110 Patient cable AE, international
20190-045 Electrode handle ICC/ACC
– Laboratory measuring cable
20194-070 Patient cable NE
or
20194-075 Patient cable NE, international
20100-033 Adapter cable NE
– HF power meter
