7 • Maintenance and servicing
60 / 84
80116-938_V24392
2023-03
Two pedal footswitch
Activation of CUT / COAG and
ReMode
1. Press the CUT pedal on the two pedal footswitch. The test program
must confirm the activation with the following entries:
– source: Illustration of a footswitch + dual-pedal foot switch +
VIO 3.
– signal: CUT
2. Press the COAG pedal on the two pedal footswitch. The test program
must confirm the activation with the following entries:
– source: Illustration of a footswitch + dual-pedal foot switch +
VIO 3.
– signal: COAG
3. Press ReMode on the two pedal footswitch. The test program must
confirm the activation with the following entries:
– source: Illustration of a footswitch + dual-pedal foot switch +
VIO 3.
– signal: REMODE
4. Remain in the Test program.
Fingerswitch activation
Test sockets
The following sockets are tested:
• MO
• MF-U
Testing and measuring equipment
Test setup
•
The test specimen is connected to the power supply via the power cord.
Finger switch activation
CUT / COAG and ReMode
Test procedure
1. Connect the electrode handle with a suitable cable to the first test
socket.
2. Press the CUT button on the electrode handle. The test program must
confirm the activation with the following entries:
– source: Illustration of a hand (for finger switch) + handpiece
+ VIO 3 + indication of the appropriate socket slot.
– signal: CUT
Erbe Art. No. Description for
20192-127 Patient cable AE MO socket
or
20192-110 Patient cable AE, international
20192-110 Patient cable AE, international MF-U socket
20190-045 Electrode handle ICC/ACC –
