5 • System settings and "Service" menu
20 / 84
80116-938_V24392
2023-03
Overview: "Service" menu
Only accessible for service personnel. Password-protected.
IMPORTANT! Regardless of the language setting selected on the unit, the "Service"
menu is only available in English.
Setting Available
from
Description
Next technical
safety check
V 1.0.x Set next technical safety check to:
advances the date for the next technical safety check by one year
(based on the system date).
V 1.0.x Actual STK date:
shows when the current technical safety check is due.
V 1.0.x System date:
shows the system date.
Test progra m s V 1.0.x Jumps to the hardware test programs.
Error List V 1.0.x Saves all errors.
Event List V 1.0.x Saves all actions and events (including user and system errors).
Operating Hours V 1.0.x Activation time: the total time of all activations.
V 1.0.x Run time: the total time during which the unit was switched on (acti-
vation time + standby).
V 1.0.x Mode activations: these are entered using the plain text of the corre-
sponding mode and the activation time.
Version List V 1.0.x Shows the version of all assemblies integrated in the unit. Shows the
version of all modules connected to the unit.
V 1.0.x System: the system as a whole; this software ID is output on the start
screen.
V 1.0.x SCM: SysCheckMaster.
V 1.0.x MCM: Measurement and Control Module.
V 1.0.x GUI: Graphical User Interface.
V 1.0.x IIM1 to 6: Instrument Interface Module, slot 1 to 6
(Slots counted from top to bottom, VIO 3: 1 to 4, APC 3: 5 to 6).
V 1.0.x NE: Return electrode.
V 1.0.x PSU: Power Supply Unit.
V 1.0.x UGM: Universal Generator Module.
V 1.0.x GCM: Gas Control Module (APC 3).
V 1.0.x FS1R: Footswitch 1 (with ReMode).
V 1.0.x FS2R: Footswitch 2 (with ReMode).
V 1.2.x GWM: Gateway module (System Integration Module)
