25 / 84
6 • Remedying malfunctions
80116-938_V24392
2023-03
CHAPTER 6
Remedying malfunctions
Safety information
ERROR list
Abbreviations of Error displays
ATTENTION! Adjustments, technical tests, modifications, maintenance and repair
work may only be performed by Erbe or persons trained by Erbe. If the
work is not performed by trained persons, Erbe accepts no liability and
warranty rights become void.
IMPORTANT! The unit generates two types of error display. System errors and user
errors. In the case of user errors, an "A" is added to the error code (e.g.
APC-A).
Display on
the unit
Detecting module
APC GCM Gas Control Module (APC 3)
EIP EIP 2 Erbe irrigation pump (from V 1.1.x)
G UGM Universal Generator Module
I IIM Instrument Interface Module
IES IES 2
or
IES
3
Intelligent evacuation system (IES 2 or IES 3
smoke evacuator from V 1.1.x)
M MCM Measurement and Control Module
N NM Nessy Module
P PSU Power Supply Unit
S SCM SysCheckMaster
U UI User Interface
W GWM Gateway module
