15 / 84
4 • Technical Data
80116-938_V24392
2023-03
CHAPTER 4
Technical Data
Power connection
Rated supply voltage 100 – 120 VAC (±10%) /
220 – 240 VAC (±10%)
Rated supply frequency 50 Hz / 60 Hz
Line current (averaged) max. 6.3 A / 2.5 A
Power input in standby mode < 30 watts
Power input with max. HF output 550 watts
Max. pulse power consumption 1600 watts
Terminal for grounding (potential equalization) yes
Power fuses T 6.3 A H / 250 V
Operating mode
Intermittent operation 25% activation time
(e.g. activated for 10 sec. / deactivated for 30 sec.)
WiFi
WiFi yes (can be activated for service purposes; always
deactivated for the intended use of the unit)
Type WLAN radio transmission: IEEE 802.11 b/g
Frequency 802.11 b/g: 2412-2462 MHz
Channels 1 - 11
Maximum output power WLAN 20 dBm
Modulation types 802.11b: DSSS (DBPSK, DQPSK, CCK)
802.11g: OFDM (BPSK, QPSK, 16QAM, 64QAM)
Available data rates 802.11b: 1, 2, 5.5, 11 Mbit/s
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbit/s
