7 • Maintenance and servicing
80116-938_V24392  2023-03
Testing and measuring equipment
IMPORTANT! The following list contains the testing and measuring equipment rec-
ommended by Erbe for servicing. Where Erbe article numbers are spec-
ified, only original Erbe testing and measuring equipment should be
used.
Erbe Art. No. Description
– Safety tester (with insulation testing > 500 V DC)
– HF power meter (RL: 50 Ohm – 5200 Ohm, measurement tolerance +7 % / -5 %)
– Oscilloscope (100 MHz and higher)
– Differential high-voltage probe (pulse-width modulation 1000:1, measurement
tolerance ±5
%)
20188-350 One pedal footswitch with ReMode
20189-350 Dual-pedal footswitch with ReMode
20190-045 Electrode handle ICC/ACC
20192-127 Patient cable AE
20192-110 Patient cable AE, international
– Laboratory measuring cable
20194-070 Patient cable NE
20194-075 Patient cable NE, international
20100-033 Adapter cable NE
20196-045 Bipolar cable
20196-053 Bipolar cable, international 2Pin 22
20196-055 Bipolar cable, international 2Pin 28
20100-034 Adapter cable bipolar
20100-035 Cable LF – leakage current
20100-038 Cable LF – leakage current, international
20100-152 BiClamp measuring cable (only if a MF socket is available)
20100-189 BiClamp MF-2 measuring cable (only if a MF-U socket is available)
20100-101 VIO Testbox Symmetry/Resistance (NE asymmetry/critical resistance)
20100-102 VIO Testbox Auto Start/Auto Stop (bipolar start/stop)
