7 • Maintenance and servicing
84 / 84
80116-938_V24392
2023-03
Test setup
Fig. 7-13
• The test specimen is connected to the power supply via the power
cord.
• The levels of power are determined with the HF power meter. The
measuring cables are plugged into the HF power meter direct.
• The dual-pedal footswitch with ReMode is connected.
Test procedure
forcedCOAG bipolar 1. Set the test specimen to:
Forceps, bipolar – forcedCOAG, bipolar – Effect 10
2. Set HF power meter to:
RL = 100 Ohm
3. Activate test specimen via COAG pedal on the footswitch.
4. Determine and document the measured value. The tolerance range is
96 to 144 watts.
