OPERATION
6-29
Figure 6-30. Location of Wire-Guides and Their Set Screws
1. Select and obtain the correct replacement wire guides (See Appendix C).
OUTPUT WIRE-GUIDE THUMB SCREW
WIRE
FROM
BOBBIN
WIRE-FEED ROLLERS
WIRE-PATH
THROUGH ASSEMBLY
CENTER WIRE-GUIDE
INPUT WIRE-GUIDE
CENTER WIRE-GUIDE SET SCREW
OUTPUT WIRE-GUIDE TUBE
NOTE
Since this is based on the size and type (steel or
aluminum) wire selected, it is assumed that the wire is
already-selected, obtained and available for this
procedure.
