223
POWERHEAD
POWERHEAD DISASSEMBLY
11
Use a punch to remove the upper crankshaft seal.
Remove and discard two crankcase head O-rings.
If the lower crankcase head is to be resealed or
the lower main bearing replaced, remove the four
bearing retainer screws. While rotating the crank-
case head, gently tap on the flange and remove
the head.
Use a punch to remove the lower crankshaft seal.
Remove and discard two crankcase head O-rings.
Remove the O-ring from crankshaft sleeve and
inspect it. Replace the O-ring if it is not in good
condition.
Inspect the crankshaft sleeve and replace, if nec-
essary. To remove the sleeve, use Slide Hammer,
P/N 432128, and Large Puller Jaws, P/N 432129.
Remove the lower main bearing only if it needs to
be replaced. Use external retaining ring pliers to
remove the lower main bearing retaining ring.
0865
1. Bearing retaining screws 000830
1. Drift punch 30297
1
1
30057
30056
30069
