272
MIDSECTION
EXHAUST HOUSING SERVICE
Loosely install the small retaining screws, nuts,
and washers.
Lubricate the upper mount with soapy water and
push into place in the adapter housing. The mount
radius must face aft with the “TOP” mark facing
up.
Apply Locquic Primer and Nut Lock to the upper
mount plate screws and install the plate and
screws loosely. Install the ground lead and star
washer under the forward starboard screw.
Align the outer exhaust housing and adapter by
placing two powerhead mounting screws through
their holes.
Install four mount plate screws and washers and
tighten to a torque of 22 to 24 ft. lbs. (30 to 33
N·m).
Tighten the small adapter to exhaust housing
screws and nuts to a torque of 60 to 84 in. lbs. (7
to 9.5 N·m).
32580
1. Powerhead mounting screws 006985
006986
13691
