Evolis PRIMACY 2 User Manual

28
PRIMACY 2

An extension for the feeder can be installed on Primacy 2.
The standard version of Primacy 2 has a feeder that can hold 100 cards. When the extension is installed, the feeder can hold 200 cards.
!
Remove all cards from the feeder before performing the installation.
Unplug the printer before performing the installation.
Keep the feeder weight. It is needed to go back to the standard version.
1
Fully open the feeder.
2
Open the cover.
Insert the block to hold the upper feeder in
place as shown and then close the cover.
3
Remove the feeder weight as shown.
4
Insert the extension until you hear a click
5
Insert cards in the feeder.
Put the weight on top of the cards.
Close the door of the feeder.
Plug the printer.
6
The 200-cards extension is installed and the
printer is ready to be used

Evolis PRIMACY 2 Specifications

General

Resolution	300 dpi
Card Format	ISO CR80 - ISO 7810 (53.98 mm x 85.60 mm)
Print Technology	Dye-sublimation
Card Capacity	100 cards (0.76 mm - 30 mil)
Card Feeding	Automatic
Card Thickness	0.25 to 1.25 mm (10 to 50 mil)
Card Types	PVC cards, Composite PVC cards, PET cards
Connectivity	USB, Ethernet
Encoding Options	Magnetic stripe encoder, Smart card contact station, Contactless card encoder
Operating Systems Supported	Windows, Mac OS, Linux
Dimensions	247 mm (H) x 205 mm (W) x 381 mm (D)
Weight	4.02 kg
Print Speed	Up to 280 cards/hour (YMCKO)
