Evolis PRIMACY 2 User Manual

33
PRIMACY 2
Double-side printing with a simplex printer
In case the double-side printing feature is not activated on your printer, proceed manually as follows:
1 2 3

The rewrite feature enables to erase and print, on rewritable cards only.
Thanks to the inner color layer of the rewritable card, there is no need to use the ribbon for
the rewrite feature.
1
Remove the ribbon and close the printer cover.
2
Open the feeder and insert rewritable cards.
If other cards are already inserted, remove them from the feeder.
3
From Evolis Premium Suite, go to Printer Settings>Printing>Rewrite.
4
Select Rewrite>Rewrite option, then the type of card:
PVC body that may be blank
or pre-printed
Thermo-sensitive layer that
contains ink which can be
either revealed or hidden,
depending on the setting

5
Select the printing mode:
• Erase /rewrite (previous data on the card are erased before printing): the full surface of
the card
• 

• Write only: there is no erase of the card before printing

Evolis PRIMACY 2 Specifications

General

Resolution	300 dpi
Card Format	ISO CR80 - ISO 7810 (53.98 mm x 85.60 mm)
Print Technology	Dye-sublimation
Card Capacity	100 cards (0.76 mm - 30 mil)
Card Feeding	Automatic
Card Thickness	0.25 to 1.25 mm (10 to 50 mil)
Card Types	PVC cards, Composite PVC cards, PET cards
Connectivity	USB, Ethernet
Encoding Options	Magnetic stripe encoder, Smart card contact station, Contactless card encoder
Operating Systems Supported	Windows, Mac OS, Linux
Dimensions	247 mm (H) x 205 mm (W) x 381 mm (D)
Weight	4.02 kg
Print Speed	Up to 280 cards/hour (YMCKO)
