Evolis PRIMACY 2 User Manual

31
PRIMACY 2
Overlay settings
Overlay settings can be adjusted in the Evolis Premium Suite.
• The overlay can be applied on the whole surface of the card
• The overlay can be disabled (when lamination is applied for example)
• The overlay can be applied only on some areas of the card
• Two layers of overlay can be applied (with the YMCKOO ribbons).
NOTE
Two layers of overlay increase protection against wear and tear


Activation key
A simplex printer (prints only on one side) can be upgraded into a duplex printer (prints on both sides).
To obtain the activation key for that upgrade, contact your Evolis dealer.
Proceed as follows:
1
Turn the printer on
2
Open the printer cover.
3
Remove the ribbon
4
Insert the key as shown

Evolis PRIMACY 2 Specifications

General

Resolution	300 dpi
Card Format	ISO CR80 - ISO 7810 (53.98 mm x 85.60 mm)
Print Technology	Dye-sublimation
Card Capacity	100 cards (0.76 mm - 30 mil)
Card Feeding	Automatic
Card Thickness	0.25 to 1.25 mm (10 to 50 mil)
Card Types	PVC cards, Composite PVC cards, PET cards
Connectivity	USB, Ethernet
Encoding Options	Magnetic stripe encoder, Smart card contact station, Contactless card encoder
Operating Systems Supported	Windows, Mac OS, Linux
Dimensions	247 mm (H) x 205 mm (W) x 381 mm (D)
Weight	4.02 kg
Print Speed	Up to 280 cards/hour (YMCKO)
