Evolis PRIMACY 2 User Manual

9
PRIMACY 2
K
J
I
H
G
F
L
N
Protective cover
O
M
F Place for reject box (See "Managing the reject box/rear output hopper",
page 18)
G Location for security locking (option)
H Power cable socket
I Ethernet connector
J USB socket (type A)
K USB socket (type B)
L Cleaning Roller
M Side panel opening mechanism
N Thermal print head with protective cover
O Card thickness adjustment gauge

Evolis PRIMACY 2 Specifications

General

Resolution	300 dpi
Card Format	ISO CR80 - ISO 7810 (53.98 mm x 85.60 mm)
Print Technology	Dye-sublimation
Card Capacity	100 cards (0.76 mm - 30 mil)
Card Feeding	Automatic
Card Thickness	0.25 to 1.25 mm (10 to 50 mil)
Card Types	PVC cards, Composite PVC cards, PET cards
Connectivity	USB, Ethernet
Encoding Options	Magnetic stripe encoder, Smart card contact station, Contactless card encoder
Operating Systems Supported	Windows, Mac OS, Linux
Dimensions	247 mm (H) x 205 mm (W) x 381 mm (D)
Weight	4.02 kg
Print Speed	Up to 280 cards/hour (YMCKO)
