EVS LSM-VIA User Manual

Available Commands
The options available for mapping to a Shortcut button are classified into categories as follows.
• Generic
◦ None (to unmap a function from a button)
◦ media currently loaded on the smallest controlled PGM:
- LSMID of the record train (local or remote)
- LSMIDof a clip (local or remote). The CAM angle loaded on the smallest controlled PGM will
be mapped to the button.
◦ current active playlist
◦ functions: 2nd Lever, Add to Shotbox, Back to Local, Character, Fast Jog, Flatten Playlist, Go to
IN, Go to OUT, Go to TC, Last Mark, Last Search TC, Loop, Mark, Page, PGMSpeed, Recall,
Record Trains, Return, Reset CAM, Search TC, Search TC Config, Sync PRV, Shotbox, Trains,
VarMax.
• Clips
◦ functions: 1-star, 2-stars, 3-stars, Add to Playlist, Archive, AUXClip, Push, Push to Favorites.
• Export
◦ list of available VIA Xsquare targets.
• Dyvi (macros)
◦ Up to 6 Dyvimacros can be mapped to Remote buttons. So, the operator will be able to trigger
the Dyvimacros from the Remote Panel console or touchscreen.
See the Prerequisites section hereafter.
• Others
◦ functions: Extract Logs, Log Point.
Prerequisites for the Use of DyviMacros
The Dyvi macros can be mapped to Shortcut buttons if the following conditions are met.
• The Enable DyviMacros parameter has been enabled from the Configuration tool.
• The DyviIP address has been appropriately set from the Configuration tool.
• The Dyvimacros have been created with the appropriate structure on the Dyviside.
a. On the Dyvi interface, inside the Global Macros folder, create a folder named LSM-VIA.
b. Create 6 macros inside the folder and name them Macro01, Macro02, and so on.
Refer to the Dyviuser manual for more information about macros.
38| January 2022 | Issue 1.4.G
