S2000 Elite - User's Guide
035-00707 Revision 1
68
43(-)
Output
Digital
Channel 1:
Used by the StepCure sequencer
Active: StepCure C1 Output is energized
Inactive: StepCure C1 Output is de-energized
26(+)
27(-)
Output
Digital
Channel 2:
Used by the StepCure sequencer
Active: StepCure C2 Output is energized
Inactive: StepCure C2 Output is de-energized
10(+)
11(-)
Output
Digital
Channel 3:
Used by the StepCure sequencer
Active: StepCure C3 Output is energized
Inactive: StepCure C3 Output is de-energized
44(+)
25(-)
Output
Digital
Green:
Green status indicator for stack lights, and Tree #1 (T1) when used in
StepCure.
Active: Status indicator is active.
Inactive: Status indicator is inactive.
8(+)
