Excelitas Technologies OmniCure S2000 Elite

S2000 Elite - User's Guide
035-00707 Revision 1
67
36
Input
Digital
Shutter Mode Select:
Deactivates the shutter verification output when active.
46
Input
Digital
Front Panel Lock:
Prevents the front panel buttons from being usable when this signal is active.
47
Input
Digital
Foot Pedal:
Simulates the activation of the foot pedal.
48
Input
Digital
Alarm Clear:
Clears and mutes any activated alarms.
49
Input
Digital
Shutter Interlock:
Prevents the shutter from being activated.
50
Input
Digital
Remote Trigger 2 Activation:
Activates Remote Trigger Input #2 (RT2) of StepCure. If no StepCure is active,
RT1 Activation will start the run profile.
6(-)
Output
Digital
Sync/Channel 0:
Reports the shutter status
Active: Shutter is open
Inactive: Shutter is closed
39(+)
