Troubleshooting

316 FTB-1v2 and FTB-1v2 Pro

Restoring Your Unit to Normal Operation

To create a WIM file for your unit:

1. From the task bar, tap the Start button ( ), and then Settings ().

2. Tap Update & security.

IMPORTANT

The size of the WIM will depend on the disk space that is currently

used on your unit.

To avoid problems, always use a USB key with an NTFS file system,

and a minimum of 16 GB of free disk space.
