Getting Started with Your Unit

34 FTB-1v2 and FTB-1v2 Pro

Attaching and Removing FTB Test Modules

To attach an FTB module to the FTB-1v2 or FTB-1v2 Pro:

1. Position the module so that its back panel rests on a flat surface such

as a table. The battery should be visible.

2. Hold the front panel so that you can see the touchscreen.

Battery

Tou chs cre en
