Getting Started with Your Unit

36 FTB-1v2 and FTB-1v2 Pro

Attaching and Removing FTB Test Modules

5. Using a flat screwdriver, turn the screws (4) clockwise until they are

tightened.

This will secure the module into its “seated” position.

When you turn on the unit, the module will be detected automatically

during the startup sequence.

Turn s c re ws

clockwise

Screws
