Getting Started with Your Unit

FTB-1v2 and FTB-1v2 Pro 67

Inserting and Removing microSD Cards

2. Position the card vertically so that its smooth edge is on the right and

you do not see its gold area. If an arrow is printed on your card, it

should point toward the bottom.

3. Slide the card into the unit’s microSD card slot, and push it all the way

to the bottom of the card slot.

The microSD card is now ready to be used.

Smooth edge of the card

Direction arrow
