Setting Up Your FTB-1v2 and FTB-1v2 Pro

74 FTB-1v2 and FTB-1v2 Pro

Adjusting Speaker and Microphone Volume

To adjust the microphone volume:

1. Ensure that your headset is connected to the audio port located on the

top panel of the unit.

2. From the main window, tap the System Settings button.

3. Tap Control Panel.

Headset/microphone port

(for 3.5 mm connector)
