IN1608 xi Scaling Presentation Switcher • SIS Configuration and Control 64
Command ASCII Command
(Host to Scaler)
Response
(Scaler to Host)
Additional Description
Output Configuration Commands, continued
Screen Saver
Set mode
E
M
X2&
SSAV
}
SsavM
X2&]
Set the color (mode) of the screen
saver to
X2&
.
View mode
E
MSSAV
} X2&]
In verbose modes 2 and 3:
SsavM
X2&]
View the color of the screen saver
(
X2&
).
Set custom color
E
C
X2*
SSAV
}
SsavC
X2*]
Set custom color
X2*
for the screen
saver.
View custom color
E
CSSAV
} X2*]
In verbose modes 2 and 3:
SsavC
X2*]
View the current custom color (
X2*
).
Set time-out duration
E
T
X2#
SSAV
}
SsavT
X2#]
Set the time-out duration to
X2#
.
View time-out duration
E
TSSAV
} X2#]
In verbose modes 2 and 3:
SsavT
X2#]
View the time-out duration.
View screen saver status
E
SSSAV
} X3*]
In verbose modes 2 and 3:
SsavS
X3*]
View the screen saver status.
Audio Configuration Commands
Audio Input Format
NOTE: For audio input format details, see Audio format on page 103.
Set audio input format
E
I
X!
*
X3%
AFMT
}
AfmtI
X!
*
X3%]
Set the audio format of input
X!
to
X3%
.
View audio input format
E
I
X!
AFMT
} X3%]
In verbose modes 2 and 3:
AfmtI
X!
*
X3%]
View the audio input format of input
X!
.
NOTES:
X!
= Input selection
1-8
X2#
= Output sync timeout
1-500 (in 1 second increments)
0 = output sync is instantly disabled with no active input
501 = output sync never times out
X2&
= Screen saver mode
0 = custom color, 1 = black output (default), 2 = blue output
X2*
= Custom screen saver color
000000 (black) to FFFFFF (white) in HTML style hexadecimal values
(for example, FF0000 = red, 00FF00 = green, and 0000FF = blue)
X3%
= Audio input format
0 = none (input muted)
1 = analog (default for inputs 1 and 2)
2 = LPCM-2Ch (default for inputs 3 and higher)
3 = Multi-Ch
4 = LPCM-2Ch auto
5 = Multi-Ch auto
X3*
= Screen saver status
0 = active input detected, timer not running
1 = no active input, timer running, output sync enabled
2 = no active input, timer expired, output sync disabled
