IN1608 xi Scaling Presentation Switcher • SIS Configuration and Control 69
Command ASCII Command
(Host to Scaler)
Response
(Scaler to Host)
Additional Description
Advanced Configuration Commands (continued)
Front Panel Lockout Mode (executive mode)
Enable mode 1
1X
Exe1
]
Lock the entire front panel.
Enable mode 2
2X
Exe2
]
Limit front panel control to input
switching and volume control only.
Disable
0X
Exe0
]
Unlock the front panel.
View status
X
X2$]
In verbose modes 2 and 3:
Exe
X2$]
View lock mode (
X2$
).
Input Aspect Ratio (per input)
Set for fill
EX!
*1ASPR
}
Aspr
X!
*1
]
Fill the entire output.
Set to follow
EX!
*2ASPR
}
Aspr
X!
*2
]
Maintain the input aspect ratio.
View aspect setting
EX!
ASPR
} X2^]
In verbose modes 2 and 3:
Aspr
X!
*
X2^]
View the aspect ratio setting
X2^
for
input
X!
.
Overscan Mode (applies only to SMPTE input resolutions)
Set value
EX#
*
X2%
OSCN
}
Oscn
X#
*
X2%]
Set the overscan value to
X2%
.
View status
EX#
OSCN
} X2%]
In verbose modes 2 and 3:
Oscn
X#
*
X2%]
View overscan setting
X2%
for input
format
X#
.
HDCP Notification (displayed on non-HDCP displays with HDCP input selected)
Enable notification
E
N1HDCP
}
HdcpN1
]
Display a green screen (default).
Disable notification
E
N0HDCP
}
HdcpN0
]
Mute output to black.
Query notification
E
NHDCP
} X(]
In verbose modes 2 and 3:
HdcpN
X(]
View HDCP notification setting
X(
.
NOTES:
X!
= Input selection
1-8
X#
= Input video format
1 = RGB, 2 = YUV, 3 = RGBcvS, 4 = S-video, 5 = Composite,
6 = HDMI
X(
= Enable or disable
0 = off or disabled, 1 = on or enabled
X2$
= Front Panel Lockout mode status
0 = off or disabled (default)
1 = mode 1 (complete front panel lockout)
2 = mode 2 (input selection and volume control only)
X2%
= Overscan
0 = 0.0% (default for RGB and HDMI)
1 = 2.5% (default for YUV, RGBcvS, S-Video, and CV)
2 = 5.0%
X2^
= Aspect ratio setting
1 = fill (default), 2 = follow
To Next Page
