Extron electronics IN1608 xi IPCP SA with LinkLicense User Manual

IN1608 xi Scaling Presentation Switcher • SIS Configuration and Control 68
Command ASCII Command
(Host to Scaler)
Response
(Scaler to Host)
Additional Description
Preset Commands (continued)
Preset Availability
Query input preset
availability
51#
X(
1
X(
2
...
X(
128
]
PreI
X(
1
...
X(
128
]
View the status of all input presets.
Verbose modes 2 and 3
Query user preset
availability
52*
X!
#
X(
1
X(
2
...
X(
16
]
In verbose modes 2 and 3:
PreU
X!
*
X(
1
...
X(
16
]
View the status of all user presets.
Advanced Configuration Commands
Test Pattern
Set pattern
EX2)
TEST
}
Test
X2)]
Set test pattern
X2)
.
View test pattern
E
TEST
} X2)]
In verbose modes 2 and 3:
Test
X2)]
View the current test pattern.
Freeze
Enable
1F
Frz1
]
Freeze the current input.
Disable
0F
Frz0
]
Unfreeze the current input.
View
F
X(]
In verbose modes 2 and 3:
Frz
X(]
View the freeze setting.
Video Switch Effect
Cut
E
0SWEF
}
Swef0
]
Set the switch effect to cut.
Fade through black
E
1SWEF
}
Swef1
]
Set the switch effect to fade through
black (default).
View setting
E
SWEF
} X3@]
In verbose modes 2 and 3:
Swef
X3@]
View the switch effect setting.
NOTES:
X!
= Input selection
1-8
X(
= Enabled or disabled
0 = off or disable, 1 = on or enable
X2)
= Test patterns
0 = none (default), 1 = crop, 2 = alternating pixels, 3 = color bars,
4 = grayscale, 5 = blue mode, 6 = audio test pattern (pink noise)
X3@
= Video switching effect
0 = cut, 1 = fade through black (default)
