Extron electronics IN1608 xi IPCP SA with LinkLicense User Manual

IN1608 xi Scaling Presentation Switcher • SIS Configuration and Control 75
Command ASCII Command
(Host to Scaler)
Response
(Scaler to Host)
Additional Description
Ethernet to RS-232 Insertion (continued)
DTP RS-232 Insertion (continued)
DTP RS-232 Output Insertion Parameters (output 3 [1C] only)
Enable RS-232 output
insertion
E
O 3*0LRPT
}
LrptO 3*0
]
Set output 3 to RS-232
pass-through.
Enable universal
asynchronous receiver-
transmitter (UART) output
insertion
E
O 3*1LRPT
}
LrptO 3*1
]
Set output 3 to Ethernet insertion.
View output insertion
setting
E
O 3LRPT
} X6(]
In verbose modes 2 and 3:
LrptO 3*
X6(]
View insertion setting
X6(
for output
3.
DTP or HDBT Switch Position (TP Format)
View switch position (TP
format)
E
O 3HDBT
} X6*]
In verbose modes 2 and 3:
HdbtO 3*
X6*]
View DTP or HDBT switch position
(selected TP format)
X6*
.
Configure Serial Port
Set serial port parameters
EX6!
*
X6@
,
X6#
,
X6$
,
X6%
CP
}
Cpn
X6!
•Ccp
X6@
,
X6#
,
X6$
,
X6%]
Set the RS-232 port parameters
View the serial port
parameters
EX6!
CP
} X6@
,
X6#
,
X6$
,
X6%]
In verbose modes 2 and 3:
Cpn
X6!
•Ccp
X6@
,
X6#
,
X6$
,
X6%]
View port parameters
X6@
,
X6#
,
X6$
,
and
X6%
of port
X6!
.
NOTES:
X6!
= Serial port number
1 = Remote port (3-pole captive screw)
7 = UART** on DTP input 7
8 = UART on DTP input 8
9 = UART on DTP/HDBT output 1C
**UART = universal asynchronous receiver-transmitter
X6@
= Baud rate
300, 600, 1200, 1800, 2400, 3600, 4800, 7200, 9600 (default),
14400, 19200, 28800, 38400, 57600, 115200
NOTE: Via PCS and the web pages, only 9600, 19200,
38400, and 115200 baud rates are selectable.
X6#
= Parity
Odd, Even, None, Mark, Space (Only the first letter is required.)
X6$
= Data bits
7 or 8 (default)
X6%
= Stop bits
1 (default) or 2
X6*
= Twisted pair format (DTP or HDBT switch
position)
0 = DTP format (Includes 12 VDC DTP remote power, default)
1 = HDBaseT format
X6(
= DTP RS-232 insertion mode
0 = RS-232 pass-through, rear panel captive screw connector
(default)
1 = IP insertion via UART
