4 Electrical installation
Festo – GDCP-CMMP-M0-HW-EN – 1511c – English 27
+24 V
external
Braking resistor
internal
alternative
Angle encoder
BR-EXT
BR-CH
BR-INT
ZK+
ZK-
L1
L2
L3
PE
24V+
GND24V
PE
U
V
W
PE
MT+
MT-
PE
BR+
Br-
E
M
3~
T
0 V
X9
X6
X2A/X2B
3-phase
Encoder/
Resolver
min. 230 V AC -10%
max. 480 V AC +10%
24 V DC supply
Connection for the outer
screening of the motor cable
L1
L2
L3
Power circuit
breakers
Fig. 4.3 CMMP-AS-...-11A-M0: Triple-phase connection to the supply voltage and the motor
