A Technical appendix
Festo – GDCP-CMMP-M0-HW-EN – 1511c – English 67
Electrical data load voltage
CMMP-AS- C2-3A-M0 C5-3A-M0 C5-11A-P3-M0 C10-11A-P3-M0
Number of
phases
1 3
Nominal voltage [V AC] 100 … 230 230 … 480
Nominal voltage
tolerance
[%] ±10 ±10
Mains frequency [Hz] 50 … 60
In continuous
operation, max.
effective nominal
current
[A] 3 6 5.5 11
Intermediate cir
cuit voltage
(without PFC)
[V DC] 310 … 320 560 … 570
Intermediate
circuit voltage
(with PFC)
[V DC] 360 … 380 –
Alternative
DC supply
[V DC] 60 … 380 60 … 700
Performance data of the PFC step with nominal supply voltage of 230 V AC ±10 %
Continuous
output
[W] 500 1000 –
Peak power [W] 1000 2000 –
Performance data of the PFC step with minimal supply voltage of 110 V AC
Continuous
output
[W] 250 500 –
Peak power [W] 500 1000 –
Tab. A.5 Technical data: Load voltage
Below the nominal power supply voltage, the PFC stage power is linearly reduced. These power charac
teristic curves are shown in the following figure.
